Order Now
$1.00
1.RF Coaxial Cable Assembly 18GHz L73P1-SMM0SMM0-1000
2.Low Loss stable phase
3.Superior Shielding Effectiveness/flexibility
描述
- RF Coaxial Cable Assembly 18GHz L73P1-SMM0SMM0-1000
2. Low Loss stable phase
3. Superior Shielding Effectiveness/flexibility
SMA Male Straight to SMA Male Straight with 7.9mm Flexible Cable 18GHz
—————- L73P1-SMM0SMM0-1000 RF Coaxial Cable Assembly ——————
Key performance:
| Cable Type | 73P1 |
| Operating Frequency(GHz) | 18 |
| Impedance (Ohm) | 50 |
| Jacket Diameter(mm) | 7.9 |
| Insulation Materials | LD PTFE |
| Minimum Static Bend Radius(mm) | 76 |
| Phase Change vs Temperature(-55°C~+85°C)(PPM) | 1200PPM |
| Shielding(dB@1GHz) | ≥90 |
| Operating Temp(°C) | -55~+125 |
Attenuation and Power Handling Capability of Cable vs Frequency:
| Frequency(GHz) | Attenuation(dB/m) | Power Handing(W) |
| 1 | 0.23 | 1200 |
| 18 | 0.78 | 387 |
